ZendHQ Z-Ray Plugins

ZendHQ Z-Ray supports plugins for PHP that are written in PHP. For installation instructions, see ZendHQ Z-Ray Plugins Installation.

This release includes the following Z-Ray plugins:

AWS plugin

The Z-Ray AWS plugin provides information on the Amazon instance ZendPHP is running on, including the instance ID, the host name, public key, and more.

This plugin only functions properly in an Amazon AWS environment.

AWS-PHP-SDK plugin

This plugin displays information about AWS SDK calls in ZendPHP Z-Ray.

Information displayed includes which call was made, what were its arguments, and what was the result of the call. Additionally, all calls are split into sub tabs according to the AWS service that was used.

Documentation for the AWS SDK for PHP is available at AWS SDK for PHP Documentation.

CodeIgniter 4 plugin

This is a plugin to add CodeIgniter 4 framework introspection to ZendHQ's Z-Ray.

Info Tab

The Info tab displays general information about CodeIgniter state.

  • baseURL: app url

  • ciVersion: framework version

  • cspEnabled: Content Security Policy, true or false

  • debugMode: Debug mode enabled, true or false

  • environment: "development" or "production"

  • locale: current locale

  • matchedRoute: current matched route and parameters

  • phpSAPI: PHP SAPI name

  • phpVersion: PHP version

  • timezone: current timezone value

Routes Tab

The Routes tab displays a table of all defined routes, methods, and handlers.

Response Tab

The Response tab provides an alternative display for response body.

Events Tab

The Events tab displays information about all triggered CodeIgniter events. It exposes the following columns:

  • Event: The event name

  • Listeners: Count of listeners for this event

  • Arguments: Arguments sent to listener, if any

  • Start time: Event timestamp

Listeners Tab

The Listeners tab displays information about event listeners. It exposes the following columns:

  • Name: The event name

  • Callback: Callback function description

Helpers Tab

The Helpers tab displays a list of loaded helper functions:

  • Name: The helper name

  • Source: The full path of the PHP file

Composer plugin

The Z-Ray plugin provides information on which Composer packages are installed, including details of each installed package, such as version, homepage, support details, and information about PHP classes loaded by Composer.

Constants plugin

The Z-Ray plugin provides PHP Constants information, system-defined and user-defined.

Doctrine 2 plugin

This is a plugin to add Doctrine 2 introspection to ZendHQ's Z-Ray.

Entities Tab

The Entities tab displays information about entities used on the current page, as well as entity mappings. It exposes the following columns:

  • Entity: Fully qualified class name of the entity class

  • Number of unique entities: How many unique objects of this entity exist

  • Number of Referenced entities: How many references exist for this entity

Queries Tab

The Queries tab displays information about executed queries, and exposes the following columns:

  • id: Query identifier number

  • Query: The executed query, along with any bound parameters

  • Count: The number of executions

  • Cached: The number of cached queries

Events Tab

The Events tab displays information about Doctrine 2 events emitted as part of Symfony\Bridge\Doctrine support. It exposes the following columns:

  • Event: The event name

  • Count: The number of occurrences

  • Listeners: Listener classes

Cache Tab

The Cache tab displays information about Doctrine 2 caches, including which cache driver is used. It exposes the following columns:

  • Type: The cache type

  • Status: Which cache driver is used

Magento plugin

This is a plugin to add Magento Open Source introspection to ZendHQ's Z-Ray.

Info Tab

The Info tab displays general information about Magento's state.

  • Name: Magento

  • Edition: edition name, either "commercial" or "community"

  • Version: current version string

  • Base path: install path

  • Front controller: controller class name

  • Action: action class name

Config Tab

The Config tab displays all settings in tree format.

Paths Tab

The Paths tab displays all defined path names.

Events Tab

The Events tab displays information about Magento 2 events emitted with defined observers. It exposes the following columns:

  • Event: The event name

  • Name: Observer name

  • Observer: Observer class

Listeners Tab

The Listeners tab displays information about "before", "around", and "after" listeners and arguments used. It exposes the following columns:

  • Call: The observer method call

  • Listener: Called listener method names

  • Arguments: Argument values provided to listener methods (cropped).

Profiler Tab

The Profiler tab captures data of Magento inner profiler. It exposes the following columns:

  • Timer Id: The name of the block of code being executed

  • Time: The time it took to complete in milliseconds

  • Average: The average time it took to complete in milliseconds

  • Count: The number of times this individual block ran to generate the output required

  • Emalloc: The amount of memory PHP assigned to this single operation. This is represented in bytes.

  • RealMem: The actual amount of memory used to perform the operation.

MongoDB plugin

This is a plugin to add MongoDB PHP Library introspection to ZendHQ's Z-Ray.

Info Tab

The Info tab displays debug information about MongoDB connection state.

  • Version: MongoDB lib version

  • URI: connection URI

  • Write operations: Counts of how many rows were modified

Query Tab

The Query tab displays information about all executed MongoDB commands. Commands are converted to SQL-like readable syntax containing JSON-formatted parameters.

It exposes the following columns:

  • ID: Command sequence number

  • Time: Time spent in milliseconds

  • Rows: Affected or matched rows count

  • Result: "ok" or "fail"

OPCache plugin

The Z-Ray OPCache plugin provides information about the PHP OPCache state, including OPCache configuration, directives, statistics, and memory usage.

Symfony

This plugin adds Symfony introspection to ZendHQ's Z-Ray.

Monolog Tab

The Monolog tab displays information about the logging activities within the application, including the log message, its severity level, and the specific channel in which the log was recorded.

Events Tab

The Events tab displays details about the dispatched events in the application, including the event name, type, dispatcher used, and whether event propagation was stopped.

Request Tab

The Request tab displays information about the HTTP request being processed, including the action taken, the controller handling the request, and relevant routing and session details.

Listeners Tab

The Listeners tab displays information about the event listeners registered in the application, specifically detailing the callable functions or methods that respond to dispatched events.

Security Tab

The Security tab displays information regarding the authentication status of users, including whether they are authenticated, their username, roles, and other relevant security attributes.

Wordpress plugin

The Z-Ray Wordpress plugin provides information about the Wordpress state. It collects general info and detailed data about cache, crons, hooks, and plugins.
