Installing ZendPHP on Windows (MSI package)

This topic describes the default procedure for installing ZendPHP on Windows using a Microsoft Installer (MSI) Package. It replaces the legacy PowerShell installation.

Note You can install multiple PHP versions in parallel for different Apache web hosting directories.

Requirements

  • Windows 10 or 11

  • Windows Server 2016 or 2019

  • 64-bit architecture only

Getting the installer

Download the MSI file for the desired version from repos.zend.com:

When prompted for username and password, use the credentials you were provided on purchase of your ZendPHP licenses to download those files.

Alternatively, provide your credentials before the host name. For example, to download version 8.3:

https://USERNAME:PASSWORD@repos.zend.com/zendphp/windows/latest/zendphp-8.3-latest-nts-x64.msi

Installing Features

You have two options how to install ZendPHP, using either the ZendHQ User Interface or the Command Line.

  • The most common way is to open the MSI file in the Windows Explorer, then following the instructions in the installer window. In this window, you also accept the license terms, select the features, extensions, and Apache.

  • Installing on the Command Line is a special scenario for experienced users. For more information about the Microsoft Installer command, see the official msiexec documentation. To install all features belonging to a level listed in the table, specify the INSTALLLEVEL property value when running msiexec. You can provide only one level value. To install certain features, specify the ADDLOCAL command line property as comma-separated list of identifiers from the table. The special value ALL selects all features.

Feature identifier
(ADDLOCAL property argument values)

Feature level
(INSTALLLEVEL property argument values)

Description

PHP_main

1

Main PHP binaries, excluding all loadable extensions and optional dependencies

PHP_bz2

2

bz2 extension

PHP_com_dotnet

2

com_dotnet extension

PHP_curl

2

curl extension

PHP_enchant

2

enchant extension

PHP_exif

2

exif extension

PHP_ffi

2

ffi extension (PHP >=7.4)

PHP_fileinfo

2

fileinfo extension

PHP_ftp

2

ftp extension

PHP_gd

2

gd extension

PHP_gettext

2

gettext extension

PHP_gmp

2

gmp extension

PHP_igbinary

2

igbinary PECL extension

PHP_imagick

2

imagick PECL extension

PHP_imap

2

imap extension

PHP_intl

2

intl extension

PHP_ldap

2

ldap extension

PHP_mbstring

2

mbstring extension

PHP_memcache

2

memcache extension

PHP_mongodb

2

mongodb PECL extension

PHP_mysql

2

mysqli and pdo_mysql extensions

PHP_oci

2

oci8 and pdo_oci extensions

PHP_odbc

2

odbc and pdo_odbc extensions

PHP_opcache

2

opcache extension

PHP_openssl

2

openssl extension

PHP_pgsql

2

pgsql and pdo_pgsql extensions

PHP_phar

2

phar extension

PHP_redis

2

redis PECL extension

PHP_shmop

2

shmop extension

PHP_snmp

2

snmp extension

PHP_soap

2

soap extension

PHP_sockets

2

sockets extension

PHP_sodium

2

sodium extension

PHP_sqlite

2

sqlite3 and pdo_sqlite extensions

PHP_sqlsrv*

2

sqlsrv and pdo_sqlsrv extensions
See the installation requirement note.

PHP_ssh2

2

ssh2 PECL extension

PHP_sysvshm

2

sysvshm extension

PHP_tidy

2

tidy extension

PHP_tokenizer

2

tokenizer extension

PHP_wddx

2

wddx extension (PHP <=7.3)

PHP_win32service

2

win32service extension

PHP_xdebug

2

xdebug extension

PHP_xmlrpc

2

xmlrpc extension (PHP <= 7.4)

PHP_xsl

2

xsl extension

PHP_zendhq

2

ZendHQ extension

DEBUG

2

debug symbol files for all PHP binaries in the package

ZEND_APACHE

3

Apache 2.4 with PHP configuration

Important To use the sqlsrv extensions, install the MS ODBC SQL drivers. Download the drivers from microsoft.com and install them manually.

Installation command examples

If you are not using the ZendHQ User Interface, you will use the command line. The MSI command has the following arguments:

# msiexec.exe /i /a <msi_file> [ADDLOCAL=feature1[,feature2...]]
                               [INSTALLEVEL=<level>]
                               [REMOVE=feature1[,feature2,...]]
                               [/quiet]

The INSTALLLEVEL argument is mutually exclusive with REMOVE and ADDLOCAL.

The following example shows a standard installation using INSTALLLEVEL:

# example for full install quietly without UI
msiexec /i zendphp-8.2.6-nts-x64.msi INSTALLLEVEL=3 /quiet

The following examples show custom installations using ADDLOCAL and REMOVE:

# example for installing PHP with curl extension for cli use without APACHE
msiexec /i zendphp-8.2.6-nts-x64.msi ADDLOCAL=PHP_main,PHP_curl /quiet
# example for installing PHP with all provided extensions except OCI extensions and Apache
msiexec /i zendphp-8.2.5-nts-x64.msi ADDLOCAL=ALL REMOVE=PHP_oci,ZEND_APACHE
# example for installing PHP with Apache and sqlite extensions
msiexec /i zendphp-8.2.5-nts-x64.msi ADDLOCAL=PHP_sqlite,ZEND_APACHE

Validating

After the installation, the default Apache configuration creates a sample page at http://<ip_address>/php<MAJOR>.<MINOR> for validation. For example, open http://127.0.0.1/php8.2 to validate that PHP 8.2 is running.

Verify that Windows Start Menu shortcuts have been created.

Installation directory structure

After the installation, familiarize yourself with the directory structure and edit the configuration files as needed. Change the web hosting directories in the Apache configuration files (ZendPHP specific setup) and provide your production web app instead of the included sample app.

The base directory may differ in different operating systems, therefore we refer to it as <BASE_DIR> in this documentation; the default 64-bit programs directory is C:\Program Files\. The default installation directory cannot be changed.

  • <BASE_DIR>\Zend\Apache24
    Contains Apache 2.4 files. Common for all ZendPHP versions.

  • <BASE_DIR>\Zend\Apache24\conf
    Contains Apache configuration files.

  • <BASE_DIR>\Zend\Apache24\conf\ZendPHP
    Contains ZendPHP configuration files for Apache web server. Included from <BASE_DIR>\Apache24\conf\httpd.conf.

  • <BASE_DIR>\Zend\Apache24\htdocs\ZendPHP\<MAJOR>.<MINOR>
    Contains a sample application for a PHP- version-specific web page. Defined in <BASE_DIR>\Apache24\conf\ZendPHP\ZendPHP<MAJOR>.<MINOR>_dir.conf.
    For production, define this value to point to your actual PHP application using a vhost configuration; a sample configuration for the vhost setup is provided in the Apache configuration directory for ZendPHP.

  • <BASE_DIR>\Zend\ZendPHP
    The base directory for ZendPHP PHP files.

  • <BASE_DIR>\Zend\ZendPHP\<MAJOR>.<MINOR>
    The subdirectory for ZendPHP version-specific files. Contains php executable files and dependency libraries.

  • <BASE_DIR>\Zend\ZendPHP\<MAJOR>.<MINOR>\etc
    Contains ZendPHP version-specific configuration files, including php.ini.

  • <BASE_DIR>\Zend\ZendPHP\<MAJOR>.<MINOR>\etc\conf.d
    Contains ZendPHP extensions configuration files. The files have the .ini extension and their names are prefixed with a prioritization number to force the required loading sequence of extensions. Do not change these prefixes.

  • <BASE_DIR>\Zend\ZendPHP\<MAJOR>.<MINOR>\ext
    Contains ZendPHP extension modules.

  • <BASE_DIR>\Zend\ZendPHP\<MAJOR>.<MINOR>\*-doc
    Contains documentation and information about PECL extensions.

  • <BASE_DIR>\Zend\ZendPHP\<MAJOR>.<MINOR>\licenses
    Contains license files for PHP and the dependency modules included in this package.

  • C:\usr\share\snmp\mibs
    Contains SNMP extension data. Only installed when you have selected the SNMP extension.

  • C:\usr\snmp
    Contains SNMP extension data. Created by the SNMP library.

SSL setup

The Secure Sockets Layer (SSL) for HTTPS requires customer certificates that you need to set up yourself. The ZendPHP installer does not provide such functionality.
For more information on SSL setup, see https://httpd.apache.org/docs/2.4/ssl/ssl_howto.html.

Updating

To update or change features, run the MSI file from Windows Explorer again, or use the Windows Control Panel tools.

The third option is to use msiexec's REMOVE property in combination with ADDLOCAL to remove features on the Command Line. Do not combine INSTALLLEVEL with REMOVE or ADDLOCAL.

# example for removing sqlsrv and pdo_sqlsrv extensions
# from current installation quietly without UI
msiexec /i zendphp-8.2.6-nts-x64.msi REMOVE=sqlsrv /quiet

Uninstalling

An uninstall shortcut for the current version is created when installing the MSI package. The package code is included in the shortcut parameter.

ZendPHP packages can be removed using Windows Control Panel tools. You can uninstall the current version by re-running the package MSI file.

Advanced users can uninstall a different version by providing a specific package code on the command line. To be able to provide upgrade functionality with MSI, the package codes change for each new build. You find the list of packages installed and their the package codes in the Windows Registry under HKLM\SOFTWARE\Microsoft\Windows\CurrentVersion\Uninstall.

# msiexec.exe /x <package_code>

For example, to remove the ZendPHP 8.2 package quietly without opening a graphical user interface, use the following command. The GUID below is just a sample, enter your package code for the specific package.

msiexec /x {B28B3FA8-9310-4AA7-B0CA-CBCCA5FD82BC} /quiet
